S9103

96.00 EUR

Information

Starters
Voltage [ V ]	12
Power [ kW ]	1.15
Rotation	CW
Size A [ mm ]	82.00
Size B [ mm ]	22.50
No./teeth [ szt ]	11
No./teeth (fits into) [ szt ]	11
No./mount. holes [ szt ]	3
No./mount. holes with thread [ szt ]	3
L.1 [ mm ]	231.00
O.1 [ mm ]	66.00
O.2 [ mm ]	67.00
O.3 [ mm ]	111.00
C.1 [ mm ]	M8x1.25
C.2 [ mm ]	M8x1.25
C.3 [ mm ]	M8x1.25

Reference number:

S9103
S9103 AS-PL
UD10937S AS-PL
AES2186 AUTOELECTRO
0001208218 BOSCH
110352 CARGO
19024839 DELCO
803000.2 ELMOT
E100L-1.5/12 ELMOT
R100.03 ELMOT
25-0079 ELSTOCK
MTD12-14 FEMSA
4474746 FIAT
4474747 FIAT
4474750 FIAT
CS139 HC PARTS
10139 KUHNER
2100-3708000 LADA
2101-3708000 LADA
2101-370800002 LADA
21213-3708010 LADA
221-3708000 LADA
3101-3708000 LADA
3708000 LADA
4233708 LADA
4253708 LADA
5722.3708 LADA
CT221128 LADA
CT22112B LADA
CT2213708000 LADA
KAT3K35.3708 LADA
KAT3KCT221126 LADA
KAT3KCT22112B LADA
LRS00286 LUCAS
63222405 MAGNETI MARELLI
63222408 MAGNETI MARELLI
63222435 MAGNETI MARELLI
63222436 MAGNETI MARELLI
63222438 MAGNETI MARELLI
63222506 MAGNETI MARELLI
E100-1.3/12V8 MAGNETI MARELLI
9141382 MAGNETON
S1024B PRESTOLITE

FIAT 131 1.4 Mirafiori [131C.000] 11.1980-01.1984
FIAT 131 1.4 Mirafiori [131C.000] 11.1981-01.1984
FIAT 131 1.4 Mirafiori [131C1.000] 11.1980-01.1984
FIAT 131 1.4 Mirafiori [131C1.000] 11.1981-01.1984
FIAT 131 1.4 Super Mirafiori [131C1.000] 04.1981-12.1983
FIAT 131 1.6 1600 [131A1.000] 10.1974-09.1981
FIAT 131 1.6 1600 Super [131C3.000] 03.1978-01.1984
FIAT 131 1.6 Panorama [131A1.000] 03.1975-12.1978
FIAT 131 1.6 Super Mirafiori [131B1.000] 03.1979-3.1982
